MAIN FEATURES

1.Independent alloy steel high pressure cylinder and pump;

2. Spatter-type lubrication system;

3. Plunger core automatic regulate service;

4. Super-hard alloy or ceramic plunger;

5. V-belt transmission;

6. Equipped with protectin unit for phase failure and over charge;

7.Intake pressure and lubricant warning device.



MODEL	PRESSURE	WATER FLOW	POWER	Plunger Diameter	STROKE
	Bar	L/min	KW	mm	mm
LF-22/15	150	22	7.5	20	32
LF-18/25	250	18	7.5	18	32
LF-14/31.5	315	14	7.5	16	32
LF-11/40	400	11	7.5	14	32
LF-8/55	550	8	7.5	12	32
LF-5.6/70	700	5.6	7.5	10	32
LF-22/25	250	22	11	20	32
LF-18/32	320	18	11	18	32
LF-14/40	400	14	11	16	32



Applications

1. Clean and test pressure of pipelines and containers in chemical plant;

2. Clean rust and dirty stuff of acid cleaning and parkerising during surface treatment;

3. Sand strip of castings;

4. Clean building templates and concrete mixer transportion device;

5. Remove oil, rust, colloid, paint, and dirty, stuff etc.;

6. Remove tree bark before root art operation.
